The 1 Piece Design Screwed End Ball Valve is a compact and efficient valve ideal for applications requiring tight shutoff and reliable performance in a wide range of industrial environments. Designed with a single-piece body and screwed end connections, this valve provides a secure and leak-proof seal, making it suitable for both high and low-pressure systems. Its simple design ensures ease of installation, maintenance, and operation, while offering durability and versatility in handling various types of fluids.
The 1 Piece Design Screwed End Ball Valve is an excellent solution for industries seeking a compact, reliable, and cost-effective valve. With its sturdy single-piece body, secure threaded connections, and versatile application range, this valve ensures efficient flow control and dependable shutoff in both industrial and commercial settings.
1 Piece Body Construction : The single-piece body design enhances structural integrity, reducing potential leak points and providing a robust and compact valve body.
Screwed End Connections : Equipped with screwed (threaded) ends, the valve offers easy installation and secure connections, making it a great choice for systems that require quick and simple setup.
Full Port Design : The full port construction ensures minimal pressure drop across the valve, allowing for efficient flow and optimal performance.
Tight Shutoff : The ball valve design provides a bubble-tight seal, preventing leakage and ensuring reliable shutoff even under varying pressure conditions.
Corrosion-Resistant Materials : Constructed from high-quality materials, the valve body and components are resistant to corrosion, extending its lifespan and suitability for a variety of media.
Low Torque Operation : The valve is designed for smooth and easy operation, requiring minimal torque to open and close, which enhances user convenience.
| Valve Details: | |
|---|---|
| Model | BV-1P/D |
| Operation | Lever |
| Size | 6 MM to 80 MM |
| Design | Investment casting, 1-piece design, full bore, blow-out proof stem, floating ball, soft-seated, non-fire safe design |
| Design & Mfg. Std. | BS 5351 (BS EN ISO 17292) |
| Inspection & Testing Std. | BS 6755 part i |
| Body | CF8 / CF8M / CF3M |
| Ball | AISI 304 / 316 / 316L |
| Seat Seal | PTFE |
| Working Temperature | Upto 1800 C |
| Working Pressure | as per 150# |
| End Connection | Screwed to BSP / BSPT / NPT |
Water Treatment and Plumbing : Ideal for water systems, the valve provides dependable shutoff and control for water and other non-corrosive fluids, commonly used in plumbing installations.
Chemical Processing : Suitable for handling a variety of chemicals and solutions, this valve is a reliable choice for low-pressure applications in chemical plants where threaded connections are preferred.
HVAC Systems : Used in heating, ventilation, and air conditioning systems to control water flow, the valve’s compact design allows for easy installation in tight spaces.
General Industrial Applications : The valve is widely used across industries for applications that require a robust, leak-proof, and manually operated valve with a simple design.
Agriculture and Irrigation : Commonly used in irrigation systems, the valve allows for precise flow control, ensuring efficient water distribution for agricultural needs.
When it comes to working with fluids under high pressure, high temperature, or possessing aggressive properties, modal selection of a valve for performance and safety reasons comes into play and becomes potent. As for heavy-duty industries, such as the oil and gas, petrochemical, power plants, water treatment plants and fabrication industries, ball valves serve a quintessential purpose by providing control over the flow. Therefore, one has to pay attention when selecting an appropriate Ball Valve Manufacturer for the needs of any industry.
Regent Hitech Private Limited, however, is one of the few elite companies that can provide structural solutions, exclusively designed for extreme industrial conditions, in the most elegant manner. Let us over explain what brands have to do so that the customer believes in their warranties and claws seven of their signatures on the products, and then what brands develop which products when there is a purposeful heavy-duty intervention for Regent Hitech Private Limited.
All industries need the services of a reputable Ball Valve Manufacturer, but not just for the sake of supplying materials—it is more about pushing the boundaries in safety through minimum interruption and effective functioning. High performance ball valves however, have to deal with the greatest forces of pressure, aggression of fluids, and constant operation.
In the event the manufacturer does not meet either design or quality expectations, it puts the entire system at risk of leaks, failure, or expensive stoppage. Due to this reason, a Ball Valve Manufacturer is regularly searched for by industries and that is one which is experienced in delivering the solution, useful and long-lasting solutions.
To function efficiently in demanding industrial settings, ball valves must be built to exceptional standards. A trusted Ball Valve Manufacturer usually focuses on several core features:
Tough environments require materials like stainless steel, duplex steel, carbon steel, or alloy steel. These metals resist corrosion, abrasion, and extreme operating conditions.
Accurate machining ensures bubble-tight sealing and smooth operation. A reputed Ball Valve Manufacturer uses CNC technology and strict dimensional accuracy for minimal leakage and maximum lifespan.
Special coatings protect ball valves from chemical reactions, rust, and wear. This directly improves valve reliability in heavy-duty zones.
Top manufacturers follow standards such as ISO, API, ASTM, and ASME. Following guidelines assures customers that each valve is safe, durable, and industrially certified.
Every industry has different needs. A flexible Ball Valve Manufacturer offers custom sizing, pressure ratings, temperature ranges, and end connections to suit specific operations.
Regent Hitech Private Limited has earned its reputation through consistent performance, innovation, and customer satisfaction. Known for designing high-performance ball valves, the company provides solutions ideal for heavy-duty industrial requirements.
Here’s what makes Regent Hitech Private Limited a standout Ball Valve Manufacturer:
The company uses advanced manufacturing technology, strict testing procedures, and modern engineering practices. Their products are designed for both maximum strength and long-term stability.
Industries dealing with harsh chemicals, steam, high-pressure lines, and abrasive slurries trust Regent Hitech Private Limited because their ball valves are built to handle demanding operational loads.
Every valve goes through hydro tests, pressure tests, and performance checks. This ensures zero leakage, consistent operation, and high safety levels.
As a leading Ball Valve Manufacturer, Regent Hitech Private Limited supplies to oil & gas, petrochemical, food processing, pharmaceuticals, water treatment, and more. Their versatility reflects the brand’s engineering capability.
Selecting the right valve requires understanding your industry’s requirements. Before purchasing, evaluate:
Ensure the chosen valve can handle maximum system pressure and temperatures. Heavy-duty lines require valves with high endurance.
For corrosive fluids, stainless steel or alloy steel is preferred. For general utility lines, carbon steel options may be used.
Choose between floating ball valves, trunnion-mounted designs, and full-port or reduced-port valves depending on the application.
Manual, motorized, pneumatic, and hydraulic actuators should match your process needs.
A trustworthy Ball Valve Manufacturer helps customers make the right selection by offering technical guidance, product data sheets, and engineering assistance.
Benefits of Choosing a Trusted Manufacturer
A high-quality Ball Valve Manufacturer delivers several benefits that directly impact industrial efficiency:
● Longer operational life
● Reduced leakage risks
● Lower maintenance cost
● Enhanced safety
● Better performance under extreme conditions
● Custom-built solutions for unique industrial challenges
These advantages help industries save time, reduce operational failures, and maintain continuous workflow.
Not every valve is suitable for demanding environments. Heavy-duty operations involve:
● Highly corrosive chemicals
● Abrasive particles
● High-speed flow
● Extreme pressure variations
● Constant operational cycles
A specialized Ball Valve Manufacturer ensures their valves are robust enough to handle these challenges without compromising safety or efficiency.
A proper selection of Ball Valve Manufacturer is very crucial in determining the systems’ overall functionality, safety and operation. Such high duty environments require very resilient, precisely designed and certified valves which are able to bear the most intense conditions.
Regent Hitech Private Limited, with the advantage of extensive experience, high technological production facilities and good experience of the industry, has developed to be one of the most reliable and competent suppliers. It is an engineering excellence and the range of products that motivate industries looking for durable quality ball valve solutions within a certain high performance range.
The 3 Piece Design Screwed End Socket Weld Ball Valve is a versatile and durable valve engineered for demanding industrial applications requiring secure shutoff, easy maintenance, and reliable flow control. With its three-piece body construction, this valve allows for convenient inline servicing without removing the entire valve from the pipeline, making it an ideal choice for systems that require frequent maintenance or where downtime needs to be minimized. The screwed end socket weld design ensures leak-proof connections and enhances overall durability, making it suitable for high-pressure and high-temperature environments.
The 3 Piece Design Screwed End Socket Weld Ball Valve is an excellent choice for industries needing a versatile, durable, and easy-to-maintain valve for high-pressure applications. Its robust construction, combined with flexible connection options and convenient inline maintenance capabilities, ensures reliable performance and cost-effective operation in various demanding environments.
Three-Piece Body Construction : The three-piece design allows for easy disassembly, maintenance, and cleaning without removing the valve from the pipeline, reducing downtime and operational costs.
Screwed End and Socket Weld Connections : The combination of threaded and socket weld connections provides secure and leak-proof installation options, allowing for flexibility in different piping systems.
Full Port Design : With a full bore opening, the valve provides unrestricted flow, minimizing pressure drop across the valve and ensuring efficient system performance.
High-Quality Sealing : The valve is equipped with advanced sealing components that provide a tight shutoff, preventing leaks and ensuring reliable operation in high-pressure applications.
Durable Materials : Constructed from corrosion-resistant materials such as stainless steel or carbon steel, the valve is suitable for handling a variety of fluids, including corrosive and abrasive media.
Easy Maintenance : The three-piece construction simplifies maintenance and repairs, allowing for the removal of the center section for cleaning or replacement without disturbing the piping connections.
| Valve Details: | |
|---|---|
| Model | BV-3P/D |
| Operation | lever / Phenumatic / Control Type |
| Size | 15 MM to 80 MM |
| Design | Investment casting, 3-piece design, full bore, blow-out proof stem, floating ball, soft-seated, non-fire safe design |
| Design & Mfg. Std. | BS 5351 (BS EN ISO 17292) |
| Inspection & Testing Std. | BS 6755 part i |
| Body | WCB / CF8 / CF8M / CF3M |
| Ball | AISI 304 / 316 / 316L |
| Seat Seal | PTFE / GFT |
| Working Temperature | Upto 180 - 2300 C |
| Working Pressure | as per 150# |
| End Connection | Screwed to BSP / BSPT / NPT, Socket Weld |
| Actuator Details: | |
|---|---|
| Method of Transmission | Double rack and pinion type |
| Actuation | Double acting - Air to open, air to close; fail-safe - Stay put |
| Body Material | Extruded aluminium, hard anodized |
| Caps and Rack | Aluminium, pressure die cast |
| Pinion | EN 8 |
| Seals | Buna-N |
| Air Pressure | Normal air supply: 5 kg/cm2 Max air supply: 7 kg/cm2 |
| Actuator Design | ISO 5211 (actuator can be quickly and easily mounted) |
| Rotation | 900 – Quarter turn |
Chemical and Petrochemical Processing : Ideal for handling a wide range of chemicals, hydrocarbons, and other corrosive fluids, the valve’s robust design and durable materials ensure long-term reliability.
Oil and Gas : Used in oil and gas pipelines for controlling the flow of crude oil, natural gas, and other fluids under high-pressure conditions. The valve’s secure connections and reliable sealing make it suitable for these demanding environments.
Pharmaceutical and Food Processing : The valve’s easy maintenance and corrosion-resistant materials make it suitable for hygienic applications, including food, beverage, and pharmaceutical processing, where frequent cleaning may be required.
Steam and Condensate Systems : Commonly used in steam and condensate systems due to its high-temperature tolerance and secure socket weld connections, providing efficient flow control in heating and cooling systems.
General Industrial Applications : Suitable for a variety of industries requiring a reliable valve for high-pressure applications, such as power generation, pulp and paper, and water treatment.
The PFA Lined Flanged Ball Valve is specifically designed for handling highly corrosive and aggressive chemicals in demanding industrial applications. This valve is lined with Perfluoroalkoxy (PFA), a high-performance fluoropolymer that provides excellent chemical resistance, ensuring safe and reliable flow control in challenging environments. The flanged end design enhances stability and leak-proof performance, making this valve an ideal choice for applications requiring superior corrosion protection and a secure, long-lasting connection to the piping system.
The PFA Lined Flanged Ball Valve is a robust and reliable solution for industries dealing with highly corrosive and hazardous chemicals. With its superior chemical resistance, durable construction, and secure flanged connections, this valve ensures safe, efficient, and long-lasting flow control in challenging environments, making it a preferred choice for applications that demand the highest level of protection and performance.
PFA Lining for Superior Chemical Resistance : The interior surfaces are lined with PFA, offering exceptional resistance to corrosive chemicals, acids, alkalis, and solvents, which extends the valve's lifespan and prevents degradation.
Flanged End Connections : The flanged ends provide secure, stable connections and ensure a leak-proof seal, suitable for high-pressure systems and applications requiring reliable performance.
Full Port Design : The full bore construction reduces pressure drop and promotes efficient fluid flow, enhancing overall system performance.
Tight Shutoff Capability : The ball valve’s design enables a bubble-tight seal, preventing leaks and ensuring safe operation, even with hazardous media.
Durable Construction : The valve body is made from corrosion-resistant materials, with PFA lining adding an extra layer of protection, making it suitable for prolonged exposure to aggressive chemicals.
Ease of Operation : The valve’s design allows for smooth and efficient manual or automated operation, requiring minimal torque to open and close.
| Valve Details: | |
|---|---|
| Model | BVPFA |
| Operation | Lever / Gear / Phenumatic |
| Size | 25 MM to 200 MM |
| Body | WCB / CF8 / CF8M / CF3M |
| Ball with Shaft | WCB / SS 304 |
| Seal | PTFE / GFT |
| Working Temperature | Upto 180- 230°C |
| Working Pressure | as per 150# |
| End Connection | Flanged End to ASME B16.5 RF (150#) |
Chemical Processing : The PFA lining provides protection against highly corrosive chemicals, making this valve ideal for controlling aggressive acids, bases, and other chemicals in processing plants.
Pharmaceutical Manufacturing : The valve’s non-reactive lining is suitable for pharmaceutical applications where maintaining purity and resisting corrosion from various solvents and chemicals is essential.
Water Treatment : Commonly used in water treatment facilities for handling corrosive media, including chlorine and other chemical additives, the valve provides safe and reliable flow control.
Food and Beverage : The PFA lining meets hygienic standards, making it suitable for handling chemicals and cleaning agents commonly used in food and beverage processing.
Pulp and Paper : This valve is used in pulp and paper production for handling bleaching agents, caustic solutions, and other chemicals, providing resistance to corrosion and ensuring process reliability.
"REGENT" is a leading Manufacturer and Exporter of Hand Lever Operated 3 Piece Design FORGED Ball Valve with Solid Ball Screwed & Socket Weld 800#.
| Valve Details: | |
|---|---|
| Design | 3 Piece design |
| Operation | Lever |
| Size | 1/2" to 2” (15mm to 50mm) |
| Design std. | BS EN 17292 |
| Material | A105N, F304, F316 |
| Pressure / Temp | ASME B 16.34 |
| Testing Std. | BS 12266-1 |
| Construction | Bolted |
| Pressure rating | ASME 800# |
| End Connection | Screwed, Socket Weld, Butt-Weld |
The 3 Piece Design Flange End Valve is meticulously engineered to meet the demands of various industrial applications requiring reliability, easy maintenance, and robust flow control. This valve features a three-piece body construction, allowing for effortless disassembly and reassembly without removing the entire valve from the pipeline. Its flanged end design ensures a secure and stable connection, making it ideal for high-pressure systems. This valve is suitable for handling a wide range of fluids, including corrosive and viscous materials, while providing excellent durability and performance.
The 3 Piece Design Flange End Valve is a dependable and efficient solution for industries requiring high performance and reliability in fluid control. Its durable design, convenient maintenance features, and secure connections make it an ideal choice for a wide range of applications, ensuring optimal performance in demanding industrial environments.
Three-Piece Body Construction : The three-piece design simplifies maintenance and servicing, allowing operators to access internal components easily without needing to disconnect the valve from the piping system.
Flanged End Connections : The flanged ends provide robust and secure connections, ensuring leak-proof performance and stability in high-pressure applications.
Full Bore Design : The full bore construction minimizes pressure drops and ensures maximum flow efficiency, making it suitable for a variety of applications requiring high flow rates.
Durable Materials : Constructed from high-quality materials such as stainless steel or carbon steel, the valve is designed to withstand harsh conditions and resist corrosion.
Versatile Sealing Options : The valve can be equipped with different sealing materials to handle a wide variety of fluids, including corrosive chemicals, steam, and oils.
User-Friendly Operation : Designed for smooth and efficient operation, the valve requires minimal effort to open and close, making it user-friendly in various settings.
| Valve Details: | |
|---|---|
| Model | BV-3P/D |
| Operation | Lever / Gear / Pneumatic / Control type |
| Size | 15 mm to 250 mm |
| Design | Investment casting 3-piece design -150 class, blow-out proof stem, floating ball, full bore ball valves |
| Design & Manufacturing Standard | BS 5351 (BS EN ISO 17292) |
| Inspection & Testing Standard | BS 6755 Part I |
| Body | WCB / CF8 / CF8M / CF3M |
| Ball | AISI 304 / 316 / 316L |
| Seat Seal | PTFE / GFT |
| Lever | Cast steel / Stainless steel with PVC sleeve |
| Working Temperature | Upto 180 - 230°C |
| Working Pressure | as per 150# / 300# |
| End Connection | Flanged end to ASME B16.5 RF (150# / 300#) |
| Actuator Details: | |
|---|---|
| Method of Transmission | Double rack and pinion type |
| Actuation | Double acting - Air to open, air to close; Fail safe - Stay put |
| Body Material | Extruded aluminium, hard anodized |
| Caps and Rack | Aluminium pressure die cast |
| Pinion | EN 8 |
| Seals | Buna-N |
| Air Pressure | Normal air supply pressure: 5 kg/cm2 Max. air supply pressure: 7 kg/cm2 |
| Actuator Design | ISO 5211 (Actuator can be quickly and easily mounted) |
| Rotation | 90° – Quarter turn |
Chemical Processing : Ideal for controlling the flow of aggressive chemicals, acids, and solvents, the valve’s durable construction and leak-proof design ensure safe and reliable operation.
Oil and Gas : Widely used in oil and gas applications, it effectively manages the flow of crude oil, natural gas, and other hydrocarbons under high pressure.
Pharmaceutical Manufacturing : The valve meets stringent hygiene and quality standards, making it suitable for pharmaceutical applications where maintaining purity is crucial.
Food and Beverage : Its corrosion-resistant materials and easy maintenance make it an excellent choice for food and beverage processing, ensuring compliance with health and safety regulations.
Water Treatment : The valve is commonly used in water treatment facilities for managing the flow of potable water, chemicals, and wastewater, offering reliability in various conditions.
